-58-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
34 Eco Fan1 Min
Fan Spinning Set at Eco (Min/Max) (0.1V)
0000-9990 110 110 110 110
35 Eco Fan1 Max 0000-9990 135 135 135 135
36 Eco Fan2 Min 0000-9990 50 50 50 50
37 Eco Fan2 Max 0000-9990 50 50 50 50
38 Eco Fan3,4 Min 0000-9990 50 50 50 50
39 Eco Fan3,4 Max 0000-9990 135 135 135 135
40 Eco Fan5 Min 0000-9990 60 60 60 60
41 Eco Fan5 Max 0000-9990 135 135 135 135
42 Eco Fan6 Min 0000-9990 50 50 50 50
43 Eco Fan6 Max 0000-9990 135 135 135 135
44 Eco Fan7 Min 0000-9990 50 50 50 50
45 Eco Fan7 Max 0000-9990 135 135 135 135
46 Eco Fan8 Min 0000-9990 50 50 50 50
47 Eco Fan8 Max 0000-9990 135 135 135 135
255 Fan Start/Cooling Setting
0 Fan1 Initial Volt
Fan Start Voltage (0.1V)
0-255 70
1 Fan2 Initial Volt 0-255 70
2 Fan3,4 Initial Volt 0-255 70
3 Fan5 Initial Volt 0-255 70
4 Fan6 Initial Volt 0-255 70
5 Fan7 Initial Volt 0-255 70
6 Fan8 Initial Volt 0-255 70
8 Cooling Time Coolong Time Setting (x30 sec.) 1: 30 3: 90 15: 450 1-15 3
10 Temp Error Cooling Time
Cooling Time Setting When the Temp Error occurs (x30 sec.)
1: 30 3: 90 15: 450
1-15 3
11 OnStart Cooling Start Threshold 0-100 50
12 After shutdown cooling Cooling Operation after Shut Down (0: No, 1: Yes) 0-1 1
256 Fan Lanp Voltage Down Setting
0 Lamp Voltage Current Lamp Voltage (0.1V) (Read only) 0-255 ---
1 Lamp Vol Threshold Threshold Voltage (0.1V) 30-90 30
2 Fan1 Speed Gain Fan Speed Ad Gain (0.1V) 0-1500 0
257 Fan Setting at Dimmer
0 Dimmer Average Check Period
Dimmer Average Check Period (sec.)
0: 10, 1: 30, 2: 60, 3: 90……10:300
0-10 1
259 Fan Air Pressure Setting
0 Press Source Range Low Pressure Sensor Control Range (AD) 0-1024 618
1 Press Source Range High 0-1024 854
2 Press Fan Add Range High Add Voltage (0.1V) 0 - 2000 0
3 Press Fan Add Range Low 0 - 2000 65
4 Temp C-A Upward High Temp C-A Upward High 0 - 1000 22
5 Temp C-A Upward Low Temp C-A Upward Low 0 - 1000 20
6 Temp C-A Downward High Temp C-A Downward High 0 - 1000 11
7 Temp C-A Downward Low Temp C-A Downward Low 0 - 1000 7
260 Auto Calibration (Common) * Auto calibration
0 Execute Calibration
Execute Calibration when the Value is changed. (For PC White
100%)
0 - 1 0
1 Loop Count Max Times of Calibration 1 - 30 8
2 Auto Status
Calibration Log (Read only)
0: Calibration End Correctly 1: On Adjusting 9: Calibration
Error
0 / 1 / 9 0
3 AutoWait Waiting time 1 - 20 3
4 CHECK - Tolerance Tolerance of Offset 1 - 255 4
5 Time out wait Wait Time until Time out [sec.] 1 - 255 20
261 Auto Calibration (RGB) PW392-AFE MDL <10bits>
0 OFFSET AREA H START Black Level Acq. Area H Start 0 - 1000 975
1 OFFSET AREA V START Black Level Acq. Area V Start 0 - 1000 500
2 GAIN AREA H START White Level Acq. Area H Start 0 - 1000 25
3 GAIN AREA V START White Level Acq. Area V Start 0 - 1000 500
4 Image AREA H WIDTH Black/White Level Area Width 0 - 4095 13
5 Image AREA V HEIGHT Black/White Level Area Height 0 - 4095 9
6 OFFSET Target Black Level Adj target 0 - 1023 20
7 OFFSET Tolerance Black Level Adj telerance 1 - 1023 1
8 GAIN Target White Level Adj target 0 - 1023 867
To Next Page
