Sanyo PLC-XP200L Service Manual

-59-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
9 GAIN Tolerance White Level Adj telerance 1 - 1023 1
10 Image Level Tolerance Acq. Image Level Adj Tolerance 1 - 255 2
262 Auto Calibration (CVBS/SVIDEO) PW392-AFE MDL <10bits>
0 Y Image Area Start X Y Image Area H Start 0 - 1000 20
1 Y Image Area Start Y Y Image Area V Start 0 - 1000 200
6 Image Area H WIDTH Image Level Acq. Width 0 - 4095 8
7 Image Area V HEIGHT Image Level Acq. Height 0 - 4095 9
8 Y Target Level Y Level Adj target 0 - 1023 808
11 Gain Tolerance Level Adj Tolerance 1 - 255 1
12 Image Level Tolerance Acq. Image Level Adj Tolerance 1 - 255 2
264 Auto Calibration (YCbCr) PW392-AFE MDL <10bits>
0 Y-OFFSET AREA H START Y - Offset Acq Area H Start 0 - 1000 925
1 Y-OFFSET AREA V START Y - Offset Acq Area V Start 0 - 1000 500
2 CB - OFFSET AREA H START CB - Offset Acq. Area H Start 0 - 1000 925
3 CB - OFFSET AREA V START CB - Offset Acq. Area V Start 0 - 1000 500
4 CR - OFFSET AREA H START CR - Offset Acq. Area H Start 0 - 1000 925
5 CR - OFFSET AREA V START CR - Offset Acq. Area V Start 0 - 1000 500
6 Y - GAIN AREA H START Y 0 - 1000 50
7 Y - GAIN AREA V START 0 - 1000 500
8 CB - GAIN AREA H START 0 - 1000 800
9 CB - GAIN AREA V START 0 - 1000 500
10 CR - GAIN AREA H START 0 - 1000 700
11 CR - GAIN AREA V START 0 - 1000 500
12 Image AREA H WIDTH YCBCR Level Acq. Width 0 - 4095 13
13 Image AREA V HEIGHT YCBCR Level Acq. Height 0 - 4095 9
14 Y - OFFSET TARGET 0 - 1023 4
15 CB OFFSET TARGET 0 - 1023 512
16 CR OFFSET TARGET 0 - 1023 512
17 Y - GAIN TARGET 0 - 1023 808
18 CB - GAIN TARGET 0 - 1023 892
19 CR - GAIN TARGET 0 - 1023 892
20 OFFSET Tolerance OFFSET Adj Tolerance 1 - 255 1
21 GAIN Tolerance GAIN Adj Tolerance 1 - 255 1
22 Image Level Tolerance Acq. Image Level Adj Tolerance 1 - 255 2
280 AutoPC Adjsut
0 AutoPCAdjustEnable
Auto PC Operation with the un-supported signal in.
0: Enable 1: Disable
0 - 1 0
1 Frequency Step TotalDot Search Step 0-3 1
2 Frequency Threshold TotalDot Match 0 - 10 5
3 Fine Phase
Phase after Total Dot Adj.
0: Fine Phase Execute 1: Fine Phase Not Execute
0 - 1 1
4 BLKDET Black Level Detect Area 0 - 7 1
5 PHASEMSK
Phase Detect Filter
0: All Bits Enable, 1: Lower 1 bit Disable, 2: Lower 2 bit Disable, 3:
Lower 3 bits Disable
0 - 3 0
300 Closed Caption
0 Caption Mode Caption Mode Select 0: OFF 1: CC1 2: CC2 3: CC3 4: CC4 0-4 0
1 Color Mode Color Mode 0: Follow to transmit Data 1: Fixed 0-1 0
500 Composite (NTSC) Composite / S-Video
1 Disp Dots 0 - 4095 668
2 H Back Porch 0 - 4095 26
3 V Back Porch 0 - 4095 18
4 Disp Line 0 - 4095 458
501 Composite (PAL) Composite / S-Video
1 Disp Dots 0 - 4095 656
2 H Back Porch 0 - 4095 35
3 V Back Porch 0 - 4095 22
4 Disp Line 0 - 4095 535
502 Composite (SECAM) Composite / S-Video
1 Disp Dots 0 - 4095 656
2 H Back Porch 0 - 4095 35
3 V Back Porch 0 - 4095 22
4 Disp Line 0 - 4095 542

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
