SATO CL4NX Programming Reference

382
Calling Example
<A>
<YR>,1
</D>,2,ABCDE
<Q>2
<Z>
Format registration No. to invoke
Field No. of print data to be changed
Data to be changed
ABCDE
Changed data
123456
Label feed direction
Available registration command is as follows.
[Available registration command]
Print position <V> <H>
<XU> <XS> <XM> <XB> <XL> <OA> <OB> <RD> <$=> <K1>
<K2> <K3> <K4> <K5> <K8> <K9> <KA> <KB> <KD> <k1>
<k2> <k3> <k4> <k5> <k8> <k9> <kA> <kB> <kD>
<U> <S> <M> <WB> <WL> <X20> <X21> <X22> <X24>
Font
<RG>
*1
<RH>
*1
Barcode <B> <BC> <BG> <BI> <D> <D><d> <BD> <BT> <BW>
Modification <P> <L> <PS> <PR> <%> <FW> <(> <WD> <KC>
system <A1> <A3>
Memory card <&R> </N> <GR> <GC>
*1 Character code: UNICODE(UTF-16BE) is not supported.
(Caution)
• The operation when registering a command other than available command is not guaranteed.
Parent topic Memory Card Command

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
