When writing 13-byte data “4912345678904” to Tag-it HF-I RFID tag, setting EAS bit to ON and
writing 10H to AFI.
(with b “Ignore RFID tag error” omitted)
<A>
<V>50<H>50<XM>4912345678904 and EAS:SET AFI:10H
<RK>2,D13,4912345678904,eas:1,afi:10
<Q>1
<Z>
[Coding sample 7](When data format is set to ASCII)
When setting EAS bit to ON and writing 10H to AFI without changing tag registration data of ICODE
SLI.
(data array to write n
～
n omitted)
<A>
<V>50<H>50<XM>EAS:SET AFI:10H
<RK>2,D0,,eas:1,afi:10
<Q>1
<Z>
[Coding sample 8](When data format is set to ASCII)
When writing 13-byte data “4912345678904” to my-d RFID tag in accordance with ISO15963
(with b “Ignore RFID tag error” omitted)
<A>
<V>50<H>50<XM>4912345678904 by ISO15693 command
<RK>5,D13,4912345678904,iso:1
<Q>1
<Z>
[Supplemental explanation]
• This command allows printing for continuous printing, cutter printing, dispenser printing and
tear-off.
•
This command cannot be specified multiple times in between <A>(start of data transmission)
through <Z>(end of data transmission). Neither can it be specified together with <IP0>(EPC
code write) command.
• Contents of sequential printing or calendar cannot be written as information to the tag.
• The sent information and written information are verified before printing when information is
written to tag with this command.
• The default value of parameter b is 0 (stop without ignoring tag error).
• If printing object doesn’t exist for the print job that includes this command, printer only writes for
RFID and doesn’t feed label. The buzzer will sound 6 times if it fails to write to tag. If successful,
the buzzer is sounded 2 times but does not feed the label. If you want to feed or print as blank
label specify 1 for the “fsw: feed without printing” field.
• Refer to the following chart if you want to specify the alphabet “A” in ASCII/HEX data formats.
Mode ASCII HEX
Data 'A' "41"
Code 41H 34H,31H
