49
[Supplementary Explanation]
• When the value outside of the range is specified for pattern, it will be processed as "0". (This will
not be a command error.)
• When the print start position exceeds the printing area, the printing is performed. (This will be a
command error.)
(When the print start position exceeds the printing area in the vertical direction, the label will be
fed.)
• When the side length is not equal to the base length, printing will not be performed due to
command error.
• This command sets the base reference point to the apex of a triangle.
<V>100
<H>200
0,0
a
a
b
a : Side length
b : Base length
• This command can be registered to the format.
• If setting the line wider, it will be widened inward.
• If the base length is odd number, +1 will be added automatically to make even number.
[Valid number]
Valid range (dots)
Side length Line width Base length
10 to 2000 1 to 1000 10 to 2000
Parent topic Modification Command
