522
Symbol Parameter name Valid range Acquisition method
SI: SIPL settings
SD: SDPL settings
ST: STCL settings
SA: AEP settings
SE: SEPL settings
c(f...) Data size of setting information
* The size of setting information is equivalent
to the bytes by section from parameter d.
The comma in between the sections is not
included.
0 to 524277 Acquire until ","
d(g...) Setting data
* text format
* Items that need to be encrypted to perform
encryption
Refer to the table of
[Setting data] below.
Data sized of setting
information
[Setting data format]
"Name of setting item" + ":" + "Setting data" + "Line feed(0DH, 0AH)"
h...h:i...i[CR][LF](j...j:k...k[CR][LF])...
[Setting data]
Symbol Parameter
name
Valid range Acquisition method
h(j ...) Setting item See Settings Table Valid until ":"
i(k ...) Setting data See Settings Table Valid until "[CR][LF]"
Data sample)
SPEED:4
LEVEL:5
[Return data format (normal)]
[ACK]<06>
16
[Return data format (when a command error occurs)]
[NAK]<15>
16
[Exception processing]
Exception conditionParameter name
A value outside the
range is specified
The specified size and
received size are different
Total number of data in bytes Command Error
Command Error
*1 *2
Identifier Invalid identifier (skip) Command Error
Data size of settings in bytes Command Error
Command Error
*3
Setting item Invalid setting item (skip)
Setting data Invalid setting item (skip)
To Next Page
