SATO CL4NX - Page 573

571
Symbol Parameter name Description
d Bytes of data Data input and output form is which case of ASCII or HEX, but, as for
the unit, the value becomes same for a byte.
e Data Refer to [Maximum return data] below.
• When the command is issued specifying "H2" (UID data) for the identifier
cc:e…e
Symbol Parameter name Description
c Identifier UI: UID data
e Data Refer to [Maximum return data] below.
• When the command is issued specifying "H3" (option flag data) for the identifier
cc:e…e,ff:h…h,ii:k…k
Symbol Parameter name Description
c / f / i Specify memory DS: DSFID data
AF: AFI data
EA: EAS bit
e / h / k Data Refer to [Maximum return data] below.
[Maximum return data]
Command identifier Current inlet type Return number of bytes
02:ICODE 160(ASCII)
320(HEX)
03:Tag-it 256(ASCII)
512(HEX)
(Custom)
1000(ASCII)
2000(HEX)
H1:USER data
05:my-d
(ISO)
992(ASCII)
1984(HEX)
H2:UID data 02:ICODE
03:Tag-it
05:my-d
16(HEX)
H3:Option flag data
(DSFID data
＋
AFI data
＋
EAS bit)
02:ICODE
03:Tag-it
05:my-d
Both of DSFID data,AFI data,EAS bit
2(HEX)
