579
Symbol Parameter name Description
e Data Refer to [Maximum return data] below.
[Maximum return data]
Command identifier Current inlet type Return number
of bytes
N1: USER data 01: ISO/IEC14443 TypeA 2048(ASCII)
4096(HEX)
N2: UID data 01: ISO/IEC14443 TypeA 14(HEX)
[Sample of status reply1] (format set to ASCII)
When '4912345678904' is recorded in the RFID tag of NTAG210 of "04 04 01 00 01 D9 CA", UID :.
Command [DC2]PJ,N1,AS
Status reply [STX]22,01,UD:13,4912345678904[ETX]
USER data
Inlet type (ISO/IEC14443 TypeA)
Command [DC2]PJ,N1,N2,AS
Status reply [STX]20,01,UD:13,4912345678904,UI:0404010001D9CA[ETX]
USER data UID data
USER data
Inlet type (ISO/IEC14443 TypeA)
Inlet type (ISO/IEC14443 TypeA)
[Sample of status reply 2] (format set to HEX)
When '4912345678904' is recorded in the RFID tag of MIFARE Ultralight of "04 07 00 00 2A C1 E2",
UID :.
Command [DC2]PJ,N1,HX
Status reply [STX]19,01,ud:13,34393132333435363738393034[ETX]
Command [DC2]PJ,N1,N2,HX
Status reply [STX]20,01, Inlet type (ISO/IEC14443 TypeA)
ud:13,34393132333435363738393034, USER data
UI:040700002AC1E2[ETX]
UID data
* It actually becomes continuous data.
USER data
Inlet type (ISO/IEC14443 TypeA)
