632
a
[Item No.] Valid range
：
00000 to 99999
*****
1. Parameter must be 5 digits parameter
2. Parameter [*] is [HEX 2AH]
3. Use item No. to be compatible with previous printers. Ignore Item No.
Always returns the status of final item.
Return status format (Legacy Status setting is valid with LAN/Wireless LAN, Other I/F)
STX Specified item
No.
*1
Specified item
status
*1
Item No. in
process
Item status in process
*2
Print quantity of item
in process
ETX
STX(HEX 02H) ETX(HEX 03H)
1 byte
5 bytes 5 bytes
2 bytes
2 bytes
1 byte
6 bytes
02H
03H
LAN/W-LAN Legacy Status for Port9100 Enable
Size STX Specified item
No.
*1
Specified item
status
*1
Item No. in
process
Item status in process
*2
Print quantity of item
in process
ETX
1 byte
5 bytes
5 bytes
2 bytes
2 bytes
1 byte
6 bytes
02H
03H
4 bytes
Numerical number in [ ] indicates the number of bytes in use. Total 22 bytes of return status format
(Fix).
Item No. is filled by "0".
Processing item No. will become Space (20h) after print.
*1 Specified item No. is ***** (0x2A2A2A2A2A) and final item status is ** (0x2A2A) fix.
*2 1st digit shows the status of processing item and 2nd digit shows the error. The following is the
chart showing status of processing items.
Digit Description ASCII HEX
Offline 0 30
Online
・
Wait for receiving 1 31
Online
・
Printing 2 32
Online
・
Waiting (Wait for dispense) 3 33
Online, Analyzing / Editing
* [Number of processing item to be printed] may not be set, which is
depending on the timing.
4 34
Error 5 35
1
Stop printing (Receiving DLE command) 6 36
Digit Description ASCII HEX
No error 0 30
Ribbon near end 1 31
Buffer near full 2 32
Ribbon near end & Buffer near full 3 33
2
Label near end 4 34
