Chapter 4 Fault diagnosis
SMSO-2-02.04- 15.07.03 119
No steam emission possible
(For other possible faults, please see “Steam generator does not heat up”)
System / component Possible cause Remedy
Water supply (water level not
reached within two minutes)
no pressure/too much pressure in pipe
system
Check water connection (supply valve at
mains connection on the premises)
Check pump pressure (see “Mainte-
nance, set pump pressure”)
Level probe faulty, or calcified, or faulty
cabling
Baffle clogged
carry out checks, and if necessary re-
place (see “control system diagram,
level probe” and “functional descriptions,
level probe”)
clean / replace
Non-return valve clogged or defective replace
Steam generator Supply pipe clogged or calcified clean / replace
Outlet valve calcified, or defective, or faulty cabling clean/ replace (see “control system
diagram, outlet valve steam”)
Electrical faults
Power PCB / power relay
Power PCB, power relay faulty check and replace the power PCB or
power relay (see control system dia-
gram, instant heater heating steam”)
Unit control system defective replace (see “Maintenance, unit control
system”)
Load machine data (counter and set-
tings) to new unit control system
Operator PCB Faulty button Dismantle the operator PCB, loosen the
PCB from the ‘top to button’, if neces-
sary dry the keyboard; refit the operator
PCB and insert into the panel.
Programming
Instant heater
Steam emission not programmed Correct the programming (see pro-
gramming instructions)
Machine or customer number pro-
grammed incorrectly
Correct the programming (see pro-
gramming instructions)
Heating time too long
System / component Possible cause Remedy
Water supply (water level not
reached within two minutes)
no pressure/too little pressure in pipe
system
Baffle clogged
Check water connection (supply valve at
mains connection on the premises)
Check pump pressure (see “Mainte-
nance, set pump pressure”)
clean / replace
Non-return valve clogged or defective
Baffle behind the non-return valve is
missing
replace
Insert baffle (see spare parts catalogue)
Instant heater Supply pipe clogged or calcified clean / replace
Heating defective or heavily calcified replace (see “Maintenance, instant
heater tea”)
