Chapter 4 Fault diagnosis
SMSO-2-02.04- 15.07.03 123
No milk/milk foam serving possible (continued)
(the milk foam contains only large bubbles…)
Programming
The milk foamer head is not enabled;
the entire milk/milk foam system dis-
abled.
Correct the programming (see pro-
gramming instructions)
Milk / milk foam too cold
System / component Possible cause Remedy
Milk system
Pipes
The milk nipple baffle on the nipple
holder is missing, or the wrong size has
been installed
replace / install a suitable baffle (see
spare parts catalogue; take note of the
diameter of the baffle)
Steam temperature programmed too low Correct the programming (see pro-
gramming instructions)
Milk foam system
Pipes
The baffle at the inlet nipple on the air
valve is missing or the wrong size is in-
stalled
replace / install a suitable baffle (see
spare parts catalogue; take note of the
diameter of the baffle)
Steam temperature programmed too low Correct the programming (see pro-
gramming instructions)
Air valve Air valve (hole for air intake) is clogged clean or replace
Milk / milk foam effervesces as the product is served
System / component Possible cause Remedy
Steam generator
Steam temperature
programmed too low
temperature too high due to faulty tem-
perature sensor (incorrect value)
Correct the programming (see pro-
gramming instructions)
Replace the temperature sensor
Hose system Hose system not water-tight; the system
contains air that should not be there.
Check the hose connections and the
hoses themselves, replace defective O-
rings, hose sockets or hoses.
Milk is too warm (often the case during
the topping up operation)
Set the control thermostat to the correct
setting (approx. 1/3 power, refrigerator
temperature approx 2
o
C – 5
o
C); see
user manual)
Milk system pipes The baffle in the milk nipple on the nip-
ple holder is dirty
clean with a micro-brush / replace with a
suitable baffle (see spare parts cata-
logue; take note of the diameter of the
baffle)
Milk foam system pipes The baffle at the inlet nipple on the air
valve is dirty
clean with a micro-brush / replace with a
suitable baffle (see spare parts cata-
logue; take note of the diameter of the
baffle)
Pinch valve Pinch valve mechanically blocked, or the
solenoid valve discharge tube is blocked
and the pinch valve is continuously
squeezing the suction hoses.
Dismantle the pinch valve and the water
cylinder if necessary, clean it and re-
place the O ring on the piston. Grease
the piston and the O-ring lightly with
grease for food applications, and then
reassemble. Check the piston for easy
action; install the water cylinder and the
pinch valve.
