Schaerer Ambiente 2 Service Manual

Chapter 5 Dismantling components
166 SMSO-2-02.05- 15.07.03
Replace the powder outlet
Preparation
 Dismantle the grinder
Service
1. Place a small screwdriver on the underside of the pow-
der outlet, and disengage the powder outlet by making a
rotating movement.
2. Move it out of the swallow tail guide, and remove
3. Set the new powder outlet into the swallow-tail guide
4. Push downwards and engage
Dismantle / replace the grinder motor
Preparation
 Dismantle the grinder
Dismantling
1. Turn the fastening screws on the grinder cup until they
come out.
2. Lift up the grinder cup
3. Attach position marks for the motor axis and at the
shock absorber drill holes
4. Unscrew the fastening screws to the motor
5. Check: the condition of the shock absorbers and decide
whether to replace with new ones or reinstall.
6. Replace the motor
Assembly
To reassemble, carry out work steps 4 … 2 … 1 in reverse
order.
