Chapter 5 Dismantling components
170 SMSO-2-02.05- 15.07.03
Replace the stripper
Preparation
Disassemble the brewing unit
Dismantle the lower piston
Service
1. Swivel the stripper downwards
2. Pull the right-hand leg from the neck bearing, guide it
downwards slightly, then let go.
3. Pull the left hand leg from the neck bearing
Installation
Carry out assembly in reverse order to the dismantling pro-
cedure.
Outlet piston Replace the O-ring
Preparation
Disassemble the brewing unit
Service
Remove / replace and pull the O-ring onto the outlet piston:
See section entitled “dismantle lower piston / replace the
O-ring”.
