Block B : Rated Data
B 01 Feed Rate Dimensions
Range: ------ t/h
----.- t/h
---.-- t/h
--.--- t/h
------ kg/h
----.- kg/h
- - -. - - kg/h
- -.- - - kg/h
Preconfigured value:------t/h
Specifying the display format for the feed rate
B 02 Nominal Feed Rate
Range: 0.0001...230,000.0t/h Preconfigured value: 400.0000 t/h
Reference for limit values and service displays.
B 03 Tacho Source
Range: DI
—
Preconfigured value: DI VFE.DI5 H
Belt-speed measurement can be switched off with —.
The nominal speed B 05 will then be used as the basis for calculation.
The DI5 digital input is the Namur input for the tachometer (see Chapter 3.2)
B 04 vs Characteristic Value
Range: 0.1...1,000,000 I/m Preconfigured value: 33.51 I/m
Number of pulses from the impulse transmitter per meter of belt length.
The product of B 04*B05must lie between the range 0.04...3,000 Hz of the speed input.
Special case: B03=—
Do not change the vs characteristic as this will alter the run time of
the setup program.
B 05 Nominal Speed
Range: 0.001...50.0 m/s Preconfigured value: 1.0000 m/s
Reference for the limit values.
40 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
