Meaning of the display
The current Fieldbus protocol is displayed (see title row), and the data selected via the
checkboxes in the window.
‘==>’ identifies data sent from the master to the scales
INTECONT® Satus..
‘<==’ identifies data of the INTECONT® Satus transferred to the master.
Meaning of the selection buttons
Record: Begin recording in the scales.
Display: The data are transferred from scales to PC and displayed. This process can take
several seconds, depending on how much data has been stored up until that moment. At
most the last (most recent) 50 telegrams can be recorded.
Copy: All (no selection), individual or a group of telegrams can be selected with the mouse
and stored in the clipboard. The data can be transferred into an editor if desired.
Checkboxes: The checkboxes are used to choose the direction of data and to activate a
time stamp.
13.4 User data diagnosis Fieldbusses
68 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
