With order inputs
It is possible to define an additional 10 order inputs, which can later be entered in the main menu by the
operator.
off: This function is switched off.
Function with remote-control software NetCom: (interface COM0 = NetCom)
The order input is configured in the software NetCom. All settings performed here at the testing device are
overwritten by the external software.
Function with remote-control software PrintCom: (interface COM0 = NetCom)
Load order: This function is not allowed.
Send order: By activating this function, the order data and the test result are sent to PrintCom.
They can be printed out via the PC. The fields are configured with the [&] button (see
below).
Function without remote-control software NetCom: (interface COM0 not set to NetCom)
Load order: (here, it has the same function)
Send order: (here, it has the same function)
Up to 10 order inputs can be configured. Together with the result, these additional
data can be printed out. The fields are configured with the [&] button (see below).
Configuration of order inputs:
After activating the [&] button, an input line appears, into which you can enter the first order definition. If
you enter a definition (e.g. order number:) and confirm with the button [Enter], the second order defintion
appears. If you enter a definition here as well (e.g. company:) and confirm it also with [Enter], the third
order input appears. This continues until the tenth order definition; or you enter no definition and confirm
the empty line with [Enter].
After this configuration, a button appears in the main menu [order data]. After activating this button, the
operator can now enter the order data, which will appear on the printing protocol.
Auftragsdaten:
Wenn der vorherige Menüpunkt „
With order inputs“ auf „Send order“ steht, kann hier ausgewählt
werden, wie die Auftragsdaten eingegeben werden sollen.
Manuell: Die Auftragsdaten können im Hauptmenü eingegeben werden.
Vor der Prüfung: Nach dem starten einer Prüfung erscheint automatisch das Eingabefenster, wo die
Auftragsdaten eingegeben werden müssen.
