Schmidt AS 990 - Page 152

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 152
Item
Designation /
Lubrication points
Lubricant

Maintenance work
 Number of
lubrication points
Maintenance interval
Operating hours
50 100 500
1
Left and right top
links
Multi-purpose
grease
4 grease nipples
Lubricate
X
2
Left and right
cylinder links
Multi-purpose
grease
4 grease nipples
Lubricate
X
3
Left and right lower
link
Multi-purpose
grease
5 lubricating nipples
Lubricate
X
4
Brush drive universal
joint
Multi-purpose
grease
1 lubricating nipple
Lubricate
X
5
Castor wheel turning
gear
Multi-purpose
grease
3 lubricating nipples
Lubricate
X
6 Castor wheel
Multi-purpose
grease
3 grease nipples
(if present)
Lubricate
X
7 Castor wheel Check diameter X
8
Suction nozzle
left and right
Check for wear X
9
Suction hose
left and right
Check for wear X
10 Cross brush
Check for damage
and wear
X
11
Wear plates
left + right
Check for wear X
