Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 36
The electrical connection (1) and the storage
compartment (2) for the hand-held control panel
is in the container box on the right-hand side at
the rear
7.3 Wanderhose
The hopper door can be fitted with a wanderhose.
This can be used for manual cleaning jobs.
The wanderhose is equipped with a separate control
panel (1). with the following functions:
Set the diesel engine speed (maximum
1,400 rpm.)
Turn on the working headlight
Activating the signal for the driver
Controlling the extension arm (depending on
the model)
7.4 Remote start connector
The remote start connector (1) can be used to
supply power to the vehicle via a special cable.
7.5 Plug-in connectors
7-pin socket (1)
Cable (2) to supply current to the
sockets (1 and 3)
12-pin socket (3)
25-pin socket (4)
1
2
1
1
2
3
4
4
