Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 157
Remove the side plate (4) by taking out the
screws (5).
Pull the outer brush (6) out of the brush shaft.
Pull the inner brush (7) out by pulling out the
telescopic brush shaft (8).
Pull the brush shaft out of the cylindrical brush.
Clean the brush housing thoroughly with water.
Installation
Assembly is carried out by reversing the
disassembly sequence.
The spline shaft (1), tappet (2) is to be cleaned
and lightly greased.
After installing, the vehicle engine is to be started
so that the air supply is re-established for the
pneumatic system.
Set the sweep range.
TIP
Do not forget. After the brushes have been
changed, reconnect the air supply from the
HGV with the ball valve for the "Raise/lower
cylindrical brush" function.
4
5
6
8
7
4
5
6
1
2
