Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 30
Debris hopper
Attached weight 5,800 kg
Hopper capacity 9.5 m
3
Hopper tipping angle: 52°
Water supply
Water tank capacity: 2,000 / 4,000 l
Debris pick-up unit
Gutter brush speed: 0 - 200 rpm
Gutter brush:
 1,000 mm
Width of suction nozzle (inner): 2 x 1,150 mm
Inner coating of suction nozzle: Rubber lining, 5 mm
Cross brush dimensions:
 400 x 2,300 mm
Castor wheels:
 250 x 80 mm
Suction hose:
 250 mm
Suction hose material: Rubber
Sweeping widths
Suction nozzle: 2,300 mm
Gutter brush with suction nozzle: 3,500 mm
Auxiliary engine EuroMot 3A
Brand: Daimler
EuroMot 3A (EU 97/68/EC) / EPA Tier 3
Model: DC-OM 906 LA
Engine capacity: 6,370 cm³
Output: 205 kW at 2,200 rpm
Torque: 1,100 kW at 1,200 rpm
Speed levels: can be set as required
Auxiliary engine EuroMot 3B
Brand: Daimler
EuroMot 3B (EU97/68/EC) / EPA Tier 4i
Model: OM 926 LA.E3B/3
Engine capacity: 7,200 cm³
Output: 210 kW at 2,200 rpm
Torque: 1,120 Nm at 1,200 rpm
Speed levels: can be set as required
Carbamide tank volume: 25 l, Diaxol (carbamide conforming to ISO 22241)
Hydraulics of AS 990
Oil tank volume/capacity: 160 /136 l
Oil to use: ATF Suffix A
