B.12
SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
UCA2 GOMSFE Models
SEL Relay Virtual Device
PPV2 Delta voltages o
PhsABf r AB voltage o METER:VAB2
PhsBCf r BC voltage o METER:VBC2
PhsCAf r CA voltage o METER:VCA2
q r Quality of data o #21
PPV3 Delta voltages o
PhsABf r AB voltage o METER:VAB3
PhsBCf r BC voltage o METER:VBC3
PhsCAf r CA voltage o METER:VCA3
q r Quality of data o #21
PPV4 Delta voltages o
PhsABf r AB voltage o METER:VAB4
PhsBCf r BC voltage o METER:VBC4
PhsCAf r CA voltage o METER:VCA4
q r Quality of data o #21
A Three-phase currents o
PhsAf r A-phase current o METER:IA
METER:ia
PhsBf r B-phase current o METER:IB
METER:ib
PhsCf r C-phase current o METER:IC
METER:ic
Neutf r Neutral current o METER:IR
q r Quality of data o #21
A1 Three-phase currents o
PhsAf r A-phase current o METER:IA1
METER:IAW1
METER:IAX
PhsBf r B-phase current o METER:IB1
METER:IBW1
METER:IBX
PhsCf r C-phase current o METER:IC1
METER:ICW1
METER:ICX
Neutf r Neutral current o METER:IR1
METER:IRX
q r Quality of data o #21
Table B.11 Polyphase Measurement Unit
Model (MMXU)—SEL Relay Connected to an SEL-2030 (Sheet 3 of 7)
FC Name r/w Description m/o Decode Method
