Schweitzer Engineering Laboratories SEL-2701 - Table B.7 Device ID Model (DI); Table B.8 Fault Identification Model (FAULT)

B.7
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
SEL Relay Virtual Device
CommID m
d
CommAdr r NSAP m #3
CommRev r SEL-2701 firmware revision
b
m#4
SftRev
c
r SEL-2701 firmware revision m #4
BootRev
c
r SEL-2701 SELBOOT revision m #5
Pro r Protocol (MMS + CASM) m “11”
Med r Physical medium o #6
Vnd
c
r Vendor m “SEL”
Mdl
c
r Model m “SEL-2701”
SerNum
c
r SEL-2701 serial number m #7
FID
c
r SEL-2701 firmware ID m #8
BootFID
c
r SEL-2701 SELBOOT code
firmware ID
m#9
a
Part name and V portion of the FID
b
R portion of the FID
c
Extension to the GOMSFE Device ID component
d
Same as the CommID of the SEL-2030
Table B.8 Fault Identification Model (FAULT)—
SEL Relay Connected to an SEL-2030 (Sheet 1 of 2)
FC Name r/w Description m/o Decode Method
MX
FltMagA Magnitude of fault currents o
PhsAf r A-phase fault current o HISTORY:IA
PhsBf r B-phase fault current o HISTORY:IB
PhsCf r C-phase fault current o HISTORY:IC
Neutf r Neutral fault current o HISTORY:IN
q r Quality of data o #21
FltMagA1 Magnitude of fault currents o
PhsAf r A-phase fault current o HISTORY:IA1
PhsBf r B-phase fault current o HISTORY:IB1
PhsCf r C-phase fault current o HISTORY:IC1
Neutf r Neutral fault current o HISTORY:IN1
q r Quality of data o #21
FltMagA2 Magnitude of fault currents o
PhsAf r A-phase fault current o HISTORY:IA2
PhsBf r B-phase fault current o HISTORY:IB2
PhsCf r C-phase fault current o HISTORY:IC2
Neutf r Neutral fault current o HISTORY:IN2
q r Quality of data o #21
Table B.7 Device ID Model (DI)—
SEL Relay Connected to an SEL-2030 (Sheet 2 of 2)
FC Name r/w Description m/o Decode Method
