Settings and Commands
Data Access Settings
The NSAP setting specifies the user-configurable portion of the full OSI
NSAP. The complete NSAP for SEL devices is 39h 84h 0Fh 80h 11h 38h 06h
00h 00h 00h 03h 00h 01h xxh xxh xxh xxh xxh xxh 01h. Set the six octets
labeled xxh with the NSAP setting. Use the SEL-2701 STATUS command to
display the full NSAP.
The proper format for the incoming control bit (CTRLB1–CTRLB64) settings
is msg:bit. The msg parameter corresponds to one of the eight GOOSE sender
ID monitor settings (GOSIED1–GOSIED8). The bit parameter indicates
either GOOSE monitor network status or a bit pair in the incoming GOOSE
message.
A bit parameter value from 1 to 160 specifies which User ST bit pair of the
incoming GOOSE message drives the corresponding control bit (CTRLB1–
CTRLB64). A bit parameter of 0 specifies that the corresponding control bit
contains the corresponding GOOSE sender monitor status. When the GOOSE
Table 3.7 SEL-2701 UCA2 Settings
Label Description Range Default
ENUCA UCA2 interface enable Y, N N
NSAP
a
a
If you change this setting and accept the new setting, the SEL-2701 closes all active network
connections and briefly pauses network operation.
Partial Network Service Access
Point (NSAP) of SEL-2701
six octets, each
0–FFh
(SEL-2701
MAC address)
ENTXGOS Outgoing GOOSE message
enable
Y
b
, N
b
Requires ENUCA set to Y to send GOOSE messages.
N
TRMULGR Outgoing GOOSE multicast
group address (xxxxh yyyyh
zzzzh)
13 characters SEL-2701 MAC
address with mode
bits set to multicast
GOSIED SEL-2701 GOOSE sender ID 66 characters Null String
GOSRPTC GOOSE sending
repeat timing coefficient
1.5–1.9 1.9
GOSIED1 GOOSE sender ID for Monitor1 66 characters Null String
GOSIED2 GOOSE sender ID for Monitor2 66 characters Null String
•
•
•
GOSIED8 GOOSE sender ID for Monitor8 66 characters Null String
CTRLB1 Incoming bit pair from GOOSE
message 1–8 to control host
Control Bit 1
msg: 1–8 bit:
0–160
Null String
CTRLB2 Incoming bit pair from GOOSE
message 1–8 to control host
Control Bit 2
msg: 1–8 bit:
0–160
Null String
CTRLB3 Incoming bit pair from GOOSE
message 1–8 to control host
Control Bit 3
msg: 1–8 bit:
0–160
Null String
•
•
•
CTRLB64 Incoming bit pair from GOOSE
message 1–8 to control host
Control Bit 64
msg: 1–8 bit:
0–160
Null String
