Schweitzer Engineering Laboratories SEL-2701 - Table B.10 Globe Model (GLOBE)-SEL Relay Connected to an SEL-2030

B.9
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
SEL Relay Virtual Device
Table B.10 Globe Model (GLOBE)—SEL Relay Connected to an SEL-2030
FC Name r/w Description m/o Decode Method
MX
ANALOG01–
ANALOG64
r Analog values o USER:ANALOG01–
USER:ANALOG64
ST
ModeDS r Device state m
b2 r Test, offline, available,
unhealthy
m #10
LocRemDS r Remote/local state m
b2 r 0-invalid, 1-local, 2-
remote
m“2”
CommSt
a
a
Extension to the GOMSFE-specified GLOBE brick
r Communications status
b2 r 0-invalid, 1-unavail-
able, 2-available
m #34
DWORD01B01–
DWORD01B16
b1 r Binary value o USER:DWORD01:0–
USER:DWORD01:15
DWORD02B01–
DWORD02B16
b1 r Binary value o USER:DWORD02:0–
USER:DWORD02:15
DWORD03B01–
DWORD03B16
b1 r Binary value o USER:DWORD03:0–
USER:DWORD03:15
•
•
•
DWORD16B01–
DWORD16B16
b1 r Binary value o USER:DWORD16:0–
USER:DWORD16:15
