Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
GOMSFE Model Example
Settings
Step 7. Set the SEL-2030 port settings and SEL-2701 settings with the
SET P 17 command. Relevant example settings are shown in
Table C.2; other settings not shown are not critical for the
example.
To add control using the GCTL model and a discrete output on the relay,
continue the serial port terminal session and follow the steps listed below:
Step 1. Connect transparently to the relay with the PORT 4 command
and enable the relay to respond to Fast Operate commands. Use
the relay SET P 3 command and set FASTOP to Y.
Step 2. Use the SET L command to set OUT103, Relay Output 3, to
RB3. This makes RB3 control OUT103.
Step 3. Terminate the transparent connection. Use the SEL-2030
transparent connection termination string (default is
CTRL + D) to terminate the transparent connection.
Step 4. Enable Fast Operate messages on the SEL-2030 Port 4 with the
SEL-2030 SET A 4 command; set SEND_OPER to Y.
Table C.1 SEL-2030 Automatic Messaging Settings
Setting Description
ISSUE1 = P00:00:01.0 Send message every second
MESG1 = 20METER Collect metering information from the relay with SEL binary
Fast Meter
ISSUE2 = P00:00:01.0 Send message every second
MESG2 = 20TARGET Collect target information from the relay with SEL binary
Fast Meter
ISSUE3 = P00:15:00.0 Send message every 15 minutes
MESG3 = 20HISTORY Collect relay history information with standard SEL message
Table C.2 SEL-2701 Settings
Setting Description
IPADDR = 10.201.0.16 IP address of SEL-2701
SUBNETM = 255.255.0.0 Subnet mask for SEL-2701 messages
DEFRTR = "10.201.0.1" Default router for messages not on the same subnet as the
SEL-2701
NETPORT = A Enable network Port A
FAILOVR = Y Enable automatic failover to Port B if network connected to
Port A fails
FTIME = 5 Five-second failover timeout
NETASPD = A Automatic speed sense (10/100 Mbps) on Port A
NETBSPD = A Automatic speed sense (10/100 Mbps) on Port B
ENUCA = Y
Enable UCA2 protocol interface
NSAP = 0030.a700.0003 User-configured portion of NSAP
