Schweitzer Engineering Laboratories SEL-2701 - Table 4.8 Example GLOBE Generic Binary Data Mapping

4.11
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
SEL-2030 Host
Data Access
Remote Bits
You can control the remote bits associated with each SEL-2030 port using the
UCA2 GCTL brick. GCTL is a generic control brick that appears in each
virtual device domain. Each GCTL brick contains 16 ST (Status) and 16 CO
(Control) bits that are associated with RB1–RB16 on that port. You can
control the remote bits by writing the 2-bit set (10) or clear (01) code to the
appropriate CO bit.
Table 4.8 Example GLOBE Generic Binary Data Mapping
Item
Port 2, Target
Region Data
Example Setting
DWORD01B01$b1 52a 001h:0;B = 2:TARGET:52A
DWORD01B02$b1 EN 001h:1;B = 2:TARGET:EN
DWORD01B03$b1 IN101 001h:2;B = 2:TARGET:IN101
DWORD01B04$b1 IN102 001h:3;B = 2:TARGET:IN102
DWORD01B05$b1 IN103 001h:4;B = 2:TARGET:IN103
DWORD01B06$b1 IN104 001h:5;B = 2:TARGET:IN104
DWORD01B07$b1 IN105 001h:6;B = 2:TARGET:IN105
DWORD01B08$b1 IN106 001h:7;B;DWORD01 = 2:TARGET:IN106
DWORD01B09$b1 Unused, 0 n/a
DWORD01B10$b1 Unused, 0 n/a
DWORD01B11$b1 Unused, 0 n/a
DWORD01B12$b1 Unused, 0 n/a
DWORD01B13$b1 Unused, 0 n/a
DWORD01B14$b1 Unused, 0 n/a
DWORD01B15$b1 Unused, 0 n/a
DWORD01B16$b1 Unused, 0 n/a
