Schweitzer Engineering Laboratories SEL-2701 - Table B.11 Polyphase Measurement Unit

B.11
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
SEL Relay Virtual Device
Vseq
a
Sequence voltages o
Posif r Positive-sequence voltage o METER:V1
Negf r Negative-sequence voltage o METER:V2
METER:3V2 #22
Zerof r Zero-sequence voltage o METER:V0
METER:3V0 #22
q r Quality of data o #21
Vseq1
a
Sequence voltages o
Posif r Positive-sequence voltage o METER:V1_1
Negf r Negative-sequence voltage o METER:V2_1
Zerof r Zero-sequence voltage o METER:V0_1
q r Quality of data o #21
Vseq2
a
Sequence voltages o
Posif r Positive-sequence voltage o METER:V1_2
Negf r Negative-sequence voltage o METER:V2_2
Zerof r Zero-sequence voltage o METER:V0_2
q r Quality of data o #21
Vseq3
a
Sequence voltages o
Posif r Positive-sequence voltage o METER:V1_3
Negf r Negative-sequence voltage o METER:V2_3
Zerof r Zero-sequence voltage o METER:V0_3
q r Quality of data o #21
Vseq4
a
Sequence voltages o
Posif r Positive-sequence voltage o METER:V1_4
Negf r Negative-sequence voltage o METER:V2_4
Zerof r Zero-sequence voltage o METER:V0_4
q r Quality of data o #21
AuxV
a
Auxiliary voltages o
f r o METER:VPL
q r Quality of data o #21
PPV Delta voltages o
PhsABf r AB voltage o METER:VAB
PhsBCf r BC voltage o METER:VBC
PhsCAf r CA voltage o METER:VCA
q r Quality of data o #21
PPV1 Delta voltages o
PhsABf r AB voltage o METER:VAB1
PhsBCf r BC voltage o METER:VBC1
PhsCAf r CA voltage o METER:VCA1
q r Quality of data o
Table B.11 Polyphase Measurement Unit
Model (MMXU)—SEL Relay Connected to an SEL-2030 (Sheet 2 of 7)
FC Name r/w Description m/o Decode Method
