UCA2 GOMSFE Models
Communications Card or Non-SEL Virtual Device
Communications Card or Non-SEL Virtual Device
The models in domains for ports where a non-SEL device (Port 1 to Port 16)
or a communications card (Port 17 or 18) is connected contain data from the
User region and are listed in Tab l e B.12. Use Math/Movement equations in the
SEL-2030 to move data elements from the data regions to the User region and
label with the required label shown in the Decode Method column.
.
Table B.12 Models in Virtual Device
Domain for Non-SEL IED Connected to an SEL-2030
Model Description
DI Relay ID information and SEL-2701 information
GCTL Control of remote bits (RB1–RB16) for port
GLOBE Basic device information
MMXU Relay metering and measurement data
MMTR Energy metering data
Table B.13 Device ID Model (DI)—Non-SEL IED Connected to an SEL-2030
FC Name r/w Description m/o Decode Method
DI r
Name r Relay ID m LOCAL:PORTID
VndID
Vnd r Vendor m “Unknown”
Mdl r Device model number
a
a
Part name and V portion of the FID
o USER:MODEL #24
SerNum r Device serial number m USER:SER_NUM #24
SftRev r Device software revision
b
b
R portion of the FID
o USER:SFT_REV #24
CommID m
c
c
Same as the CommID of the SEL-2030
CommAdr r NSAP m #3
CommRev r SEL-2701 firmware revi-
sion
b
m#4
SftRev
d
d
Extension to the GOMSFE Device ID component
r SEL-2701 firmware revision m #4
BootRev
d
r SEL-2701 SELBOOT revision m #5
Pro r Protocol (MMS + CASM) m “11”
Med r Physical medium o #6
MAC r Medium access control o #7
Vnd
d
r Vendor m “SEL”
Mdl
d
r Model m “SEL-2701”
SerNum
d
r SEL-2701 serial number m #7
FID
d
r SEL-2701 firmware ID m #8
BootFID
d
r SEL-2701 SELBOOT code
firmware ID
m#9
