Schweitzer Engineering Laboratories SEL-2701 - SEL-2030 Domains

B.3
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
SEL-2030 Domains
SEL-2030 Domains
An SEL-2030 contains the domains shown in Table B.2. The SEL-2701 uses
each port database to create a virtual device with the domain name
DDaaname. The SEL-2701
determines the name portion of the domain name
using the rules described in Section 3: Settings and Commands
.
Tabl e B. 2 S EL - 20 30 Dom a ins
Domain Description
LN0 Logical Device 0 domain containing SEL-2030 information
DD01name Virtual Device 1 domain containing data from Port 1 database
DD02name Virtual Device 2 domain containing data from Port 2 database
DD03name Virtual Device 3 domain containing data from Port 3 database
•
•
•
•
•
•
DD17name Virtual Device 17 domain containing information on Port 17 protocol
card and from database
DD18name Virtual Device 18 domain containing information on Port 18 protocol
card and Port 18 database
