Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
SEL-2030 Host
Settings
Settings
Access the settings for the SEL-2701 using the SEL-2030 settings commands
and the port number (17 or 18) where the SEL-2701 is installed. These
commands provide access to some additional settings that govern how the
SEL-2030 interacts with the SEL-2701. This section only describes the
SEL-2030 settings and behavior specific to installations that include an
SEL-2701. See the SEL-2030 Reference Manual for complete syntax and
examples for SEL-2030 commands.
Port Settings
Use the SEL-2030 port settings to set the SEL-2701 for operation on your
network. SEL-2030 port settings also include the SEL-2701 settings described
in Section 3: Settings and Commands.
Access these settings using the SET P n command, where n is the port
number (17 or 18) where the SEL-2701 is installed. Port settings for an
SEL-2030 port with an installed SEL-2701 are listed in Ta ble 4.1. SEL-2030
port control settings with details are listed in Table 4.2.
Automatic
Message Settings
The SEL-2030 uses the NOCONN SELOGIC control equation to determine
whether to allow external connections to the port in question. Access
Automatic Message settings using the SET A n command, where n is the port
number (17 or 18) where the SEL-2701 is installed.
The NOCONN setting, shown in Table 4.3 , controls the following Telnet
connections for the SEL-2701:
➤ Telnet connections to the SEL-2030 through the SEL-2701
➤ Telnet connections out of the SEL-2030 through the SEL-2701
Table 4.1 SEL-2030 Port Settings With SEL-2701 Installed
Settings Reference
SEL-2030 Port Control Tab le 4 .2
Network Configuration Table 3.1 on page 3.2 in Section 3: Settings and Commands
Network Address
Resolution
Table 3.3 on page 3.4 in Section 3: Settings and Commands
FTP Table 3.5 on page 3.6 in Section 3: Settings and Commands
Telnet Table 3.6 on page 3.7 in Section 3: Settings and Commands
UCA2 Table 3.7 on page 3.8 in Section 3: Settings and Commands
Table 4.2 SEL-2030 Port Control Settings With SEL-2701 Installed
Label Description Range Default
SENDTIME Enable/disable time synchronization of
the SEL-2701 from the SEL-2030
Y/N N
TIMEOUT Timeout period for
Virtual Terminal connection
OFF, 0–30
minutes
OFF
TERTIME1 Length of time the channel must be idle
before checking for the termination string
0–600
seconds
1
TERSTRING Transparent communication
termination string
\004 which is
CTRL + D
TERTIME2 Length of time the channel must be idle
before accepting the termination string
0–600
seconds
0
