SEL-400 Series Host
Settings
Settings
Access the settings for the SEL-2701 using the relay settings commands and
the port number where the SEL-2701 is installed. These commands provide
access to some additional settings that govern how the relay interacts with the
SEL-2701. This section only describes the relay settings and behavior specific
to installations that include an SEL-2701. See the relay instruction manual for
complete syntax and examples for relay commands.
Port Settings
Use the relay port settings to set the SEL-2701 for operation on your network.
SEL-400 series relay port settings also include the SEL-2701 settings
described in Section 3: Settings and Commands.
Access these settings with the relay SET P n command, where n is the port
number where the SEL-2701 is installed. Port settings for a relay port with an
installed SEL-2701 are listed in Table 5.1. Relay port control settings with
details are listed in Table 5.2.
Outgoing
Control Points
Outgoing control points are used by the relay to send binary information to the
SEL-2701. The SEL-2701 uses these bits for protocol-specific operations. For
example, the SEL-2701 generates GOOSE messages using the outgoing
control points. Access settings for outgoing control points using the SET O n
command, where n is the port number where the SEL-2701 is installed.
Table 5.1 SEL-400 Series Relay Port Settings With SEL-2701 Installed
Settings Reference
Relay Port Control Tab le 5.2
Network Configuration Table 3.1 on page 3.2 in Section 3: Settings and Commands
Network Address
Resolution
Table 3.3 on page 3.4 in Section 3: Settings and Commands
FTP Table 3.5 on page 3.6 in Section 3: Settings and Commands
Telnet Table 3.6 on page 3.7 in Section 3: Settings and Commands
UCA2 Table 3.7 on page 3.8 in Section 3: Settings and Commands
Table 5.2 SEL-400 Series Relay Port Control Settings With SEL-2701 Installed
Label Description Range Default
TIMEOUT Timeout period for
virtual terminal connection
Off, 0–60
minutes
5
AUTO Port auto-message enable Y, N Y
FASTOP Fast operate message enable Y, N Y
TERTIM1 Length of time the channel must be idle
before checking for the termination string
0–600
seconds
1
TERSTRN Transparent communication
termination string
Up to 9
characters
\005 which is
CTRL + E or \006
which is CTRL + F
TERTIM2 Length of time the channel must be idle
before accepting the termination string
0–600
seconds
0
