SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
SEL-2030 Host
Settings
The SEL-2030 Reference Manual describes SELOGIC control equations and
their syntax. SEL
OGIC control equations are a language for entering Boolean
expressions into the SEL-2030. If the SEL
OGIC control equations expression
evaluates to false or logical 0, the SEL-2701 allows Telnet connections. When
the expression evaluates to true or logical 1, the SEL-2701 does not allow new
connections and terminates any existing Telnet connections.
Math/Data
Movement Settings
Complete User region settings and data storage are available for each port
with an installed protocol card. User region data are available to the user for
data concentration and manipulation. User region data are also used for some
protocols including UCA2. Access Math/Data Movement settings using the
SET M n command where n is the port number (17 or 18) where the
SEL-2701 is installed.
Outgoing Control
Point Settings
Outgoing control points are used by the SEL-2030 to send binary information
to the SEL-2701. The SEL-2701 uses these bits for protocol-specific
operations. For example, the SEL-2701 generates GOOSE messages using the
outgoing control points. Access settings for outgoing control points using the
SET O n command, where n is the port number (17 or 18) where the
SEL-2701 is installed.
Table 4.3 SEL-2030 Automatic Message Settings With SEL-2701 Installed
Label Description Range Default
NOCONN Block external
connections to this port.
SELOGIC control equation NA
