Settings and Commands
SEL-2701 Commands
SEL-2701 Commands
The SEL-2701 user interface accepts SEL-2701 commands. There are two
ways you can connect to the SEL-2701. First, if your host allows, you can
make a transparent connection to the SEL-2701. Second, you can establish a
Telnet connection to the SEL-2701 user interface. See the host-specific
sections for more information on connecting to the SEL-2701 user interface.
Other connections to the SEL-2701, including FTP, require standard protocol
commands and do not respond to the SEL-2701 user-interface commands.
Using Commands
When you type commands, you can type in either the entire command or just
use the first three letters. For example, if you type STATUS ENTER or STA
ENTER the SEL-2701 displays status information. Commands are not case
sensitive; you may use upper- or lower-case characters. Access level password
entry is case sensitive. Tabl e 3.9 summarizes the user commands.
As with serial ports on SEL devices, you can control character transmission in
a Telnet session using control characters. Send the control characters listed in
Table 3.8 to control long transmissions like event reports and SER reports.
Command Summary
Table 3.9 summarizes the SEL-2701 commands. Subsequent subsections
provide full descriptions of each command in alphabetical order.
Table 3.8 Control Characters
Control Characters Key Commands Results
XON CTRL + Q Restart paused transmission and enable
subsequent transmissions.
XOFF CTRL + S Pause current transmission and block any
subsequent transmissions.
CAN CTRL + X Cancel current transmission or command and
return to cursor.
Table 3.9 SEL-2701 Command Summary
Command Description Access Level
2ACCESS Go to Access Level 2. 1
ACCESS Go to Access Level 1. 0 or 2
DATE View or change date. 1
a
or 2
a
Limited functions at this access level. See command description below for details.
GOOSE View/reset UCA network GOOSE ID information. 2
HELP Display available commands or command help. Any
ID View internal identification parameters for the
SEL-2701.
1 or 2
MEMORY Display RAM statistics for the SEL-2701. 1 or 2
PING Ping another node on the network. 2
QUIT Go to Access Level 0. Any
STATUS Display self-test status. 1 or 2
TIME View or change internal clock. 1
a
or 2
