B.29
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
Special Translation Rules
Special Translation Rules
The rules listed in Table B.18 apply to the GOMSFE models shown in the
preceding paragraphs of this appendix.
Table B.18 Special Translation Rules
# Rule
1 Device model number from FID string
2 Software revision code from FID string
3 Communications address (NSAP)
4 SEL-2701 software revision code
5 SEL-2701 SEL
BOOT software revision code
6 Current physical medium being used
7 SEL-2701 serial number
8 SEL-2701 FID
9 SEL-2701 SEL
BOOT FID
10 Status based on Host Status Register and local status
11 Target rows 5 and 6
12 Preset value for DNA outputs
13 Force value for DNA inputs
14 Default value for DNA inputs
15 Access card date and time
16 Selection for DNA outputs
17 Selection for DNA inputs
18 Control to force SEL-2701 to reacquire GOOSE addresses
19 Last value written to control points
20 Operate control points to host
21 Communication failure, Comm Fail, quality indication based on state of port
from LOCAL:PORT_STATUS or forced if associated data are forced
22 Quantity scaled down by factor of three
23 Unit quantities based on default units for each item
24 Item at given label treated as a null-terminated string
25 Preset value for UserSt outputs
26 Force value for UserSt inputs
27 Default value for UserSt inputs
28 Selection for UserSt outputs
29 Selection for UserSt inputs
30 Fields labeled MONTH, DAY, YEAR, HOUR, MIN, SEC, and MSEC, con-
verted to date/time
31 Targets bit map as shown in Table B.19 on page B.30
32 Fault types as shown in Table B.20 on page B.30
33 Common fault types as shown in Table B .20
34 Base communications status on LOCAL:PORT_STATUS Bit 9
