B.25
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
Communications Card or Non-SEL Virtual Device
Table B.17 Polyphase Meter Unit Model (MMTR)—
Non-SEL IED Connected to an SEL-2030 (Sheet 1 of 4)
FC Name r/w Description m/o Decode Method
MX
WHr Per-phase energy o
PhsAf r A-phase energy o USER:EA
PhsBf r B-phase energy o USER:EB
PhsCf r C-phase energy o USER:EC
q r Quality of data o #21
WHr1 Per-phase energy o
PhsAf r A-phase energy o USER:EA1
PhsBf r B-phase energy o USER:EB1
PhsCf r C-phase energy o SER:EC1
q r Quality of data o #21
WHr2 Per-phase energy o
PhsAf r A-phase energy o USER:EA2
PhsBf r B-phase energy o USER:EB2
PhsCf r C-phase energy o USER:EC2
q r Quality of data o #21
WHr3 Per-phase energy o
PhsAf r A-phase energy o USER:EA3
PhsBf r B-phase energy o USER:EB3
PhsCf r C-phase energy o USER:EC3
q r Quality of data o #21
WHr4 Per-phase energy o
PhsAf r A-phase energy o USER:EA4
PhsBf r B-phase energy o USER:EB4
PhsCf r C-phase energy o USER:EC4
q r Quality of data o #21
TotWHr Total energy o
f r Total energy o USER:E
q r Quality of data o #21
TotWHr1 Total energy o
f r Total energy o USER:E1
q r Quality of data o #21
TotWHr2 Total energy o
f r Total energy o USER:E2
q r Quality of data o #21
TotWHr3 Total energy o
f r Total energy o USER:E3
q r Quality of data o #21
To Next Page
