B.24
SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
UCA2 GOMSFE Models
Communications Card or Non-SEL Virtual Device
Var2 Per-phase reactive power o
PhsAf r A-phase reactive power o USER:QA2
PhsBf r B-phase reactive power o USER:QB2
PhsCf r C-phase reactive power o USER:QC2
q r Quality of data o #21
Var3 Per-phase reactive power o
PhsAf r A-phase reactive power o USER:QA3
PhsBf r B-phase reactive power o USER:QB3
PhsCf r C-phase reactive power o USER:QC3
q r Quality of data o #21
Var4 Per-phase reactive power o
PhsAf r A-phase reactive power o USER:QA4
PhsBf r B-phase reactive power o USER:QB4
PhsCf r C-phase reactive power o USER:QC4
q r Quality of data o #21
TotVAr Total reactive power o
f r Total reactive power o USER:Q
q r Quality of data o #21
TotVAr1 Total reactive power o
f r Total reactive power o USER:Q1
q r Quality of data o #21
TotVAr2 Total reactive power o
f r Total reactive power o USER:Q2
q r Quality of data o #21
TotVAr3 Total reactive power o
f r Total reactive power o USER:Q3
q r Quality of data o #21
TotVAr4 Total reactive power o
f r Total reactive power o USER:Q4
q r Quality of data o #21
Hz System frequency o
f r System frequency o USER:FREQ
q r Quality of data o #21
a
Extension to the GOMSFE MMXU brick
Table B.16 Polyphase Measurement Unit
Model (MMXU)—Non-SEL IED Connected to an SEL-2030 (Sheet 6 of 6)
FC Name r/w Description m/o Decode Method
