B.23
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
Communications Card or Non-SEL Virtual Device
W2 Per-phase power o
PhsAf r A-phase power o USER:PA2
PhsBf r B-phase power o USER:PB2
PhsCf r C-phase power o USER:PC2
q r Quality of data o #21
W3 Per-phase power o
PhsAf r A-phase power o USER:PA3
PhsBf r B-phase power o USER:PB3
PhsCf r C-phase power o USER:PC3
q r Quality of data o #21
W4 Per-phase power o
PhsAf r A-phase power o USER:PA4
PhsBf r B-phase power o USER:PB4
PhsCf r C-phase power o USER:PC4
q r Quality of data o #21
TotW Total (Three-phase) power o
f r Total power o USER:P
q r Quality of data o #21
TotW1 Total (Three-phase) power o
f r Total power o USER:P1
q r Quality of data o #21
TotW2 Total (Three-phase) power o
f r Total power o USER:P2
q r Quality of data o #21
TotW3 Total (Three-phase) power o
f r Total power o USER:P3
q r Quality of data o #21
TotW4 Total (Three-phase) power o
f r Total power o USER:P4
q r Quality of data o #21
Var Per-phase reactive power o
PhsAf r A-phase reactive power o USER:QA
PhsBf r B-phase reactive power o USER:QB
PhsCf r C-phase reactive power o USER:QC
q r Quality of data o #21
Var1 Per-phase reactive power o
PhsAf r A-phase reactive power o
PhsBf r B-phase reactive power o USER:QB1
PhsCf r C-phase reactive power o USER:QC1
q r Quality of data o #21
Table B.16 Polyphase Measurement Unit
Model (MMXU)—Non-SEL IED Connected to an SEL-2030 (Sheet 5 of 6)
FC Name r/w Description m/o Decode Method
