Installation
Initial Checkout
Step 6. Enter the STATUS command to confirm there are no SEL-2701
self-test errors. A report for a functional SEL-2701 displays
Normal (0h) for each port where an SEL-2701 is installed, as
shown for Port 17 and Port 18 in Figure 2.3. If the SEL-2030
reports an error on Port 17 or 18, see Section 6:
Troubleshooting for a detailed description of the error.
*>STATUS
COMMUNICATIONS PROCESSOR-S/N 2001051089 Date: 03/16/01 Time: 16:00:03
FID=SEL-2030-R113-V0-Z000000-D20010122 FID=SLBT-2030-R103-V0-Z000000-D20010122
SELF-TESTS
RAM SRAM CODE ARCH EEPROM P.S. SET BATTERY
512 kb 1024 kb OK 2048 kb OK OK OK OK
IRIG-B Input: Absent
I/O Board: Installed
Port Status Success Rate SET M Database Delays
1 Inactive None
2 Active None
3 Active None
4 Active None
5 Active None
6 Active None
7 Active None
8 Active None
9 Active None
10 Active None
11 Active None
12 Active None
13 Active None
14 Active None
15 Active None
16 Active None
17 Normal(0h) NORM None
18 Normal(0h) NORM None
F Active 88% None
*>
Figure 2.3 SEL-2030 STATUS Command.
Step 7. Proceed to Section 3: Settings and Commands for information
on network settings needed to operate the SEL-2701 on a
network.
SEL-400 Series
Relay Installations
Use the steps below to verify that the SEL-2701 is installed properly and
initializes correctly in an SEL-400 series relay.
Step 1. Apply power to the relay. The initial power-up sequence takes
as long as one minute.
Step 2. Establish a terminal connection from your PC to the SEL-400
series relay.
Step 3. Enter the ACC command to log in to Access Level 1.
Step 4. Enter the STA A command to confirm that the SEL-400 series
relay detects the SEL-2701 and that there are no SEL-2701
self-test errors. If the relay reports an error, see Section 6 for a
detailed description of the error.
