SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
UCA2 GOMSFE Models
SEL-2030 Domain–LNO
SEL-2030 Domain–LNO
Each device on a UCA2 network has a Logical Device 0 domain, LN0. The
models in this domain contain data specific to the SEL-2030. Data elements
for each model type are listed in Table B .4 and Table B.5 on page B.5. The
models in the LN0 domain are listed in Table B.3.
Table B.3 Models in LN0 Domain
Model Description
DI Device identification data
GLOBE Basic device and GOOSE information
Table B.4 Device ID Model (DI)—SEL-2030
FC Name r/w Description m/o Decode Method
DI r Device information
Name r Relay ID m GLOBAL:HOST_ID
VndID m
Vnd r Vendor m “SEL”
Mdl r Device model number
a
a
Part name and V portion of the FID
m GLOBAL:FID #1
SerNum r Device serial number m GLOBAL:SER_NUM
SftRev r Device software revision
b
b
R portion of the FID
m GLOBAL:FID #2
BootRev
c
c
Extension to the GOMSFE Device ID component
r Boot code software revision m GLOBAL:BFID #2
FID
c
r Device firmware ID string m GLOBAL:FID
BootFID
c
r Device boot code firmware
ID string
m GLOBAL:BFID
CommID
CommAdr r NSAP m #3
CommRev r SEL-2701 firmware revision
b
m#4
SftRev
c
r SEL-2701 firmware revision m #4
BootRev
c
r SEL-2701 SELBOOT revision m #5
Pro r Protocol (MMS + CASM) m “11”
Vnd
c
r Vendor m “SEL”
Mdl
c
r Model m “SEL-2701”
SerNum
c
r SEL-2701 serial number m #7
FID
c
r SEL-2701 firmware ID m #8
BootFID
c
r SEL-2701 SELBOOT code
firmware ID
m#9
