SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
Installation
Initial Checkout
Initial Checkout
SEL-2030
Installations
Use the steps below to verify that the SEL-2701 is installed properly and
initializes correctly in an SEL-2030.
Step 1. Apply power to the SEL-2030. The initial power-up sequence
takes at least one minute.
Step 2. Observe the SEL-2030 front-panel card status LEDs.
➢ The Card 1 and Card 2 LEDs indicate the status of the
protocol cards on Port 17 and Port 18, respectively.
When the SEL-2030 and SEL-2701 complete the
power-up sequence, the LED will begin to flash if the
SEL-2701 is operating correctly. Proceed with Step 3.
➢ If after several minutes the LED is still on, power up
initialization has failed. Proceed with Step 3 (Step 5 and
Step 6 may provide additional information about the
SEL-2701 status).
➢ If you have installed an SEL-2701 and the LED is off,
then the SEL-2030 is not detecting the card. Return to
Installation on page 2.2 and follow the steps to verify
proper installation.
Step 3. Establish a terminal connection from your PC to the SEL-2030.
Step 4. Enter the ACC command to log in to Access Level 1.
Step 5. Enter the WHO command to confirm that the SEL-2030
detects the SEL-2701 correctly on Port 17 or 18. Line 18 of
Figure 2.2 shows the response to the WHO command when a
single SEL-2701 is installed in the SEL-2030 (Port 18).
*>WHO
COMMUNICATIONS PROCESSOR-S/N 2001051089 Date: 03/16/01 Time: 15:59:02
FID=SEL-2030-R113-V0-Z000000-D20010122 FID=SLBT-2030-R103-V0-Z000000-D20010122
Port# Device Protocol Parameters Identification
1 SEL IED SEL 9600,8,2,N
2 Other IED Ascii 9600,8,2,N
3 Other IED Ascii 9600,8,2,N
4 Other IED Ascii 9600,8,2,N
5 Other IED Ascii 9600,8,2,N
6 Other IED Ascii 9600,8,2,N
7 Other IED Ascii 9600,8,2,N
8 Master SEL 9600,8,2,N
9 Printer Ascii 9600,8,2,N
10 Other IED Ascii 9600,8,2,N
11 Other IED Ascii 9600,8,2,N
12 Other IED Ascii 9600,8,2,N
13 Other IED Ascii 9600,8,2,N
14 Other IED Ascii 9600,8,2,N
15 Other IED Ascii 9600,8,2,N
16 Other IED Ascii 9600,8,2,N
18 SEL-2701 Ethernet VTm:HS,CTl:HS,TIm:S,SBt:S
F* Master SEL 9600,8,2,N
*>
Figure 2.2 SEL-2030 WHO Command.
