B.16
SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
UCA2 GOMSFE Models
SEL Relay Virtual Device
VAr4 Per-phase reactive power o
PhsAf r A-phase reactive power o METER:QA4
PhsBf r B-phase reactive power o METER:QB4
PhsCf r C-phase reactive power o METER:QC4
q r Quality of data o #21
TotVAr Total reactive power o
f r Total reactive power o METER:Q
q r Quality of data o #21
TotVAr1 Total reactive power o
f r Total reactive power o METER:Q1
q r Quality of data o #21
TotVAr2 Total reactive power o
f r Total reactive power o METER:Q2
q r Quality of data o #21
TotVAr3 Total reactive power o
f r Total reactive power o METER:Q3
q r Quality of data o #21
TotVAr4 Total reactive power o
f r Total reactive power o METER:Q4
q r Quality of data o #21
Hz System frequency o
f r System frequency o METER:FREQ
q r Quality of data o #21
CF
All MMXU.MX r Configuration of data m
u r Units for all items m #23
a
Extension to the GOMSFE MMXU brick
Table B.11 Polyphase Measurement Unit
Model (MMXU)—SEL Relay Connected to an SEL-2030 (Sheet 7 of 7)
FC Name r/w Description m/o Decode Method
