UCA2 GOMSFE Models
SEL Relay Virtual Device
W4 Per-phase power o
PhsAf r A-phase power o METER:PA4
PhsBf r B-phase power o METER:PB4
PhsCf r C-phase power o METER:PC4
q r Quality of data o #21
TotW Total (Three-phase) power o
f r Total power o METER:P
q r Quality of data o #21
TotW1 Total (Three-phase) power o
f r Total power o METER:P1
q r Quality of data o #21
TotW2 Total (Three-phase) power o
f r Total power o METER:P2
q r Quality of data o #21
TotW3 Total (Three-phase) power o
f r Total power o METER:P3
q r Quality of data o #21
TotW4 Total (Three-phase) power o
f r Total power o METER:P4
q r Quality of data o #21
VAr Per-phase reactive power o
PhsAf r A-phase reactive power o METER:QA
PhsBf r B-phase reactive power o METER:QB
PhsCf r C-phase reactive power o METER:QC
q r Quality of data o #21
VAr1 Per-phase reactive power o
PhsAf r A-phase reactive power o METER:QA1
PhsBf r B-phase reactive power o METER:QB1
PhsCf r C-phase reactive power o METER:QC1
q r Quality of data o #21
VAr2 Per-phase reactive power o
PhsAf r A-phase reactive power o METER:QA2
PhsBf r B-phase reactive power o METER:QB2
PhsCf r C-phase reactive power o METER:QC2
q r Quality of data o #21
VAr3 Per-phase reactive power o
PhsAf r A-phase reactive power o METER:QA3
PhsBf r B-phase reactive power o METER:QB3
PhsCf r C-phase reactive power o METER:QC3
q r Quality of data o #21
Table B.11 Polyphase Measurement Unit
Model (MMXU)—SEL Relay Connected to an SEL-2030 (Sheet 6 of 7)
FC Name r/w Description m/o Decode Method
