B.14
SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
UCA2 GOMSFE Models
SEL Relay Virtual Device
Aseq2
a
Sequence currents o
Posif r Positive-sequence current o METER:I1_2
Negf r Negative-sequence current o METER:I2_2
METER:3I2Y #22
Zerof r Zero-sequence current o METER:I0_2
q r Quality of data o #21
Aseq3
a
Sequence currents o
Posif r Positive-sequence current o METER:I1_3
Negf r Negative-sequence current o METER:I2_3
Zerof r Zero-sequence current o METER:I0_3
q r Quality of data o #21
Aseq4
a
Sequence currents o
Posif r Positive-sequence current o METER:I1_4
Negf r Negative-sequence current o METER:I2_4
Zerof r Zero-sequence current o METER:I0_4
q r Quality of data o #21
AuxA1
a
Auxiliary currents o
f r o METER:IP
METER:IPOL
q r Quality of data o #21
WPer-phase powero
PhsAf r A-phase power o METER:PA
PhsBf r B-phase power o METER:PB
PhsCf r C-phase power o METER:PC
q r Quality of data o #21
W1 Per-phase power o
PhsAf r A-phase power o METER:PA1
PhsBf r B-phase power o METER:PB1
PhsCf r C-phase power o METER:PC1
q r Quality of data o #21
W2 Per-phase power o
PhsAf r A-phase power o METER:PA2
PhsBf r B-phase power o METER:PB2
PhsCf r C-phase power o METER:PC2
q r Quality of data o #21
W3 Per-phase power o
PhsAf r A-phase power o METER:PA3
PhsBf r B-phase power o METER:PB3
PhsCf r C-phase power o METER:PC3
q r Quality of data o #21
Table B.11 Polyphase Measurement Unit
Model (MMXU)—SEL Relay Connected to an SEL-2030 (Sheet 5 of 7)
FC Name r/w Description m/o Decode Method
