B.10
SEL-2701 Ethernet Processor Instruction Manual Date Code 20020501
UCA2 GOMSFE Models
SEL Relay Virtual Device
Table B.11 Polyphase Measurement Unit
Model (MMXU)—SEL Relay Connected to an SEL-2030 (Sheet 1 of 7)
FC Name r/w Description m/o Decode Method
MX Measurement
V Three-phase voltage o
PhsAf r A-phase voltage o METER:VA
METER:va
PhsBf r B-phase voltage o METER:VB
METER:vb
PhsCf r C-phase voltage o METER:VC
METER:vc
Neutf r Neutral voltage o METER:VN
q r Quality of data o #21
V1 Three-phase voltage o
PhsAf r A-phase voltage o METER:VA1
METER:VAX
PhsBf r B-phase voltage o METER:VB1
METER:VBX
PhsCf r C-phase voltage o METER:VC1
METER:VCX
Neutf r Neutral voltage o METER:VN1
q r Quality of data o #21
V2 Three-phase voltage o
PhsAf r A-phase voltage o METER:VA2
METER:VAY
PhsBf r B-phase voltage o METER:VB2
METER:VBY
PhsCf r C-phase voltage o METER:VC2
METER:VCY
Neutf r Neutral voltage o METER:VN2
q r Quality of data o #21
V3 Three-phase voltage o
PhsAf r A-phase voltage o METER:VA3
PhsBf r B-phase voltage o METER:VB3
PhsCf r C-phase voltage o METER:VC3
Neutf r Neutral voltage o METER:VN3
q r Quality of data o #21
V4 Three-phase voltage o
PhsAf r A-phase voltage o METER:VA4
PhsBf r B-phase voltage o METER:VB4
PhsCf r C-phase voltage o METER:VC4
Neutf r Neutral voltage o METER:VN4
q r Quality of data o #21
