Schweitzer Engineering Laboratories SEL-2701 - Page 107

B.19
Date Code 20020501 SEL-2701 Ethernet Processor Instruction Manual
UCA2 GOMSFE Models
Communications Card or Non-SEL Virtual Device
Table B.16 Polyphase Measurement Unit
Model (MMXU)—Non-SEL IED Connected to an SEL-2030 (Sheet 1 of 6)
FC Name r/w Description m/o Decode Method
MX
V Three-phase voltage o
PhsAf r A-phase voltage o USER:VA
PhsBf r B-phase voltage o USER:VB
PhsCf r C-phase voltage o USER:VC
Neutf r Neutral voltage o USER:VN
q r Quality of data o #21
V1 Three-phase voltage o
PhsAf r A-phase voltage o USER:VA1
PhsBf r B-phase voltage o USER:VB1
PhsCf r C-phase voltage o USER:VC1
Neutf r Neutral voltage o USER:VN1
q r Quality of data o #21
V2 Three-phase voltage o
PhsAf r A-phase voltage o USER:VA2
PhsBf r B-phase voltage o USER:VB2
PhsCf r C-phase voltage o USER:VC2
Neutf r Neutral voltage o USER:VN2
q r Quality of data o #21
V3 Three-phase voltage o
PhsAf r A-phase voltage o USER:VA3
PhsBf r B-phase voltage o USER:VB3
PhsCf r C-phase voltage o USER:VC3
Neutf r Neutral voltage o USER:VN3
q r Quality of data o #21
V4 Three-phase voltage o
PhsAf r A-phase voltage o USER:VA4
PhsBf r B-phase voltage o USER:VB4
PhsCf r C-phase voltage o USER:VC4
Neutf r Neutral voltage o USER:VN4
q r Quality of data o #21
Vseq
a
Sequence voltages o
Posif r Positive-sequence voltage o USER:V1
Negf r Negative-sequence voltage o USER:V2
Zerof r Zero-sequence voltage o USER:V0
q r Quality of data o #21
