Date Code 20181001 SEL-3031 Instruction Manual
Section 3
Job Done Examples
Overview
This section has four job done examples of how to easily set up the SEL-3031 for
common applications. This section assumes you have established a radio link. If you
are having problems setting up the radio link, refer to Section 2: Installation and
Section 5: Performance Monitoring, Testing, and Troubleshooting for more
information.
This section contains four Job Done examples for the following applications.
➤ High-Speed Teleprotection or Control With M
IRRORED BITS
Communications
➤ Using an SEL Information Processor to Collect Relay Status and
Measurements
➤ Setting Up a Point-to-Multipoint Link Using DNP3 SCADA Protocol
➤ Configuring Collocated Antennas Using SEL Hop-Sync Technology
High-Speed Teleprotection or Control With
MIRRORED BITS Communications
Figure 3.1 SEL MIRRORED BITS Connection Example
SEL-351
SEL-2505
SEL-2100
SEL-3031
SEL-3031
