Date Code 20181001 SEL-3031 Instruction Manual
Job Done Examples
Using an SEL Information Processor to Collect Relay Status and Measurements
3.9
*>>AUTO 2 <Enter>
FID: FID=SEL-351S-7-R106-V0-Z003003-D20010110
DEVICE ID: FEEDER 1
BAUD RATE: 19200
OPERATE SUPPORT: Binary (1 Breakers, 16 Remote Bits S-C-P)
LEVEL 1 PASSWORD: OTTER
COMMANDS SUPPORTED:
B 20METER
B 20DEMAND
B 20TARGET
A 20HISTORY
A 20STATUS
A 20EVENT
A 20EVENTS
A 20EVENTL
*>>
Figure 3.10 Example AUTO Command Output
The AUTO command verifies initial configuration is set up. Refer to the SEL-2032
Instruction Manual for more information on setting up Fast Messaging.
