Date Code 20181001 SEL-3031 Instruction Manual
Settings and Commands
Settings
4.9
File > Read
Select File > Read to cause QuickSet to read the device settings from a connected
device. As QuickSet reads the device, a Transfer Status window will appear. QuickSet
uses serial protocols to read settings from SEL devices.
Device Editor (Editor Mode)
Use the Device Editor (Editor Mode) to enter and display settings. Make sure that the
firmware in your radio matches the QuickSet settings driver; the driver version number
in the lower left corner of the Device Editor should be equal to the first three digits
following “Z” in the radio Firmware Identification (FID) string. Use the ID or STA
command to easily view the FID string.
Entering Settings
Step 1. Click + in the Settings Tree View to expand and select the settings
you want to change.
Step 2. Click Tab to navigate through the settings, or click on a setting.
Step 3. Right-click your mouse in the setting dialog box and select Previous
Value to restore the previous value for a setting.
Step 4. Right-click your mouse in the setting dialog box and select Default
Value to restore the factory-default setting value.
If you enter a setting that is out of range or has an error, QuickSet will show the error at
the bottom of the Settings Editor. Double-click the error listing to go to the setting and
enter a valid input.
Sending Settings
Select Save, Send, or Print Device Settings from the File menu of the Device Editor
once settings are entered into QuickSet. This will ensure that your settings are not lost.
Table 4.2 Device Editor Menus
Menus Description
<< >> Moves from one category to the next.
Merge Merges the open record with another record.
Compare Compares the open record with another record.
Search Searches for a particular setting.
Part Number Displays part number.
