Date Code 20181001 SEL-3031 Instruction Manual
Settings and Commands
Commands
4.25
Append the specific setting name you want to change in the SET command to
immediately jump to the setting. If s is not entered, the device starts at the first setting.
For example, to directly jump to the TXPWR setting in the Radio setting category,
enter SET R TXPWR <Enter>. This will take you directly to the TXPWR setting.
If you want to set all of the Radio settings, issue the SET R command and it will start
at the beginning of the settings list. Enter the desired setting value or press <Enter> to
accept the existing setting, as shown in Table 4.20.
The device checks each setting to ensure that it is within the allowed range. If the
setting is not within the allowed range, the device generates an
Out of Range
message and prompts you for the setting again. When all the settings are entered, the
device displays the new settings and prompts you for approval to enable them. Answer
Y <Enter> to enable the new settings. The device is disabled for no longer than one
second while saving the new settings. The ALARM LED illuminates momentarily and the
ENABLED LED extinguishes while the device is disabled.
SHOW Command
When showing settings, the radio displays the settings label and the present value from
nonvolatile memory for each setting class as shown in Table 4.21.
Table 4.19 SET Command (Change Settings)
Command Description Access Level
SET G s
a
a
s = specific setting name.
Set Global settings 2
SET R s Set Radio settings 2
SET P s Set serial Port settings 2
Table 4.20 SET Command Editing Keystrokes
Press Key Results
<Enter> Retains the setting and moves to the next setting.
^<Enter> Returns to the previous setting.
< <Enter> Returns to the previous setting category.
> <Enter> Moves to the next setting category.
END <Enter> Exits the editing session, then prompts you to save the settings.
<Ctrl+X> Aborts the editing session without saving changes.
