1 - 110
2. Setting the Parameter
[1] [MDI] mode
[2] Reset state
[3] Turn on the [WRITE] switch.
[4] Rewriting of parameters is enabled (SETTING screen)
[5] Move the cursor to the number you want to set
[6] Input the setting data with the keys
[7]
Press the INPUT key
3. Parameters Related to Tool Life
• No. 8001 #6 ...........Sets the tool life in terms of times when deleting all the data.
• No. 8001 #7 ...........Sets the tool life in terms of minutes when deleting all the modes.
• No. 8003 #0 ...........Spare tool position output 1 to 9
• No. 8003 #7 ...........Clears the tool status and life use value when downloading the life set
value by M57.
• No. 8060 ................% data marked by “
” in the TOOL STATUS LIST screen (Standard
value: 80)
• No. 8078 ................In call number offset, tool numbers greater than this number will be
call numbers for the spare tools. (Standard value: 1000)
18-11 Alarms
780 BROKEN TOOL WAS SELECTED
This alarm is issued when a broken tool is called to the spindle position. When manually
resetting this alarm, check and change the tool and reset the alarm.
After replacing the tool by a new one, clear the life use value and tool status for the old
tool.
781 OUT-OF-LIFE TOOL WAS SELECTED
This alarm is issued when an out-of-life tool is called to the spindle position. When
manually resetting this alarm, check and change the tool and reset the alarm.
After replacing the tool by a new one, clear the life use value and tool status for the old
tool.
782 PREMACHINING TOOL CHECK ERROR
One of the tools checked in a premachining tool check was found defective (out of life,
broken, and so on)
Replace the defective tool by a new one and clear the life use value and tool status for
the defective tool.
783 CUTTING MONITORING FORMAT ERROR
There is a programming error in premachining tool check or tool life data automatic
setting.
Correct a program command and rerun.
